Axiomtek – a world-renowned leader relentlessly devoted to the research, development, and manufacture of a series of innovative and reliable industrial computer products of high efficiency – is proud to announce the release of the GOT712A, a 12.1-inch EN-certified fanless touchscreen panel PC designed for railway human-machine interface (HMI) applications. Featuring a sunlight-readable XGA TFT LCD, a fanless wide-temperature design, and a full-range, railway-grade power architecture, it is well-suited for driver cabs, onboard control panels, and monitoring systems operating in harsh railway environments.
Why is GOT712A a Reliable Touchscreen Panel PC for Railway HMI Systems?
Railway-Certified Reliability for Onboard Deployment
The GOT712A is ready for market with COC-ready EN 50155 and EN 45545-2 certifications, simplifying the validation and compliance process for customers. Its wide operating temperature range of -40°C to +70°C (EN 50155 OT4) and 24 to 110 VDC wide-range power input (EN 50155 S2) guarantee reliable operation across diverse global climates and voltage challenges. Furthermore, the IP65-rated aluminum front bezel, fanless design, and M12-type lockable connectors minimize connection failure risks from vibration, dust, and moisture.
Maximum Flexibility: Versatile I/O and Expansion to Accelerate Solution Development
Powered by the quad-core Intel Atom® x6425E processor (12W TDP), the power-efficient system features comprehensive railway interfaces, including one CAN bus, dual 2.5 Gigabit Ethernet, dual COM, dual USB 2.0 signal, and one DIO (6-in/2-out). A standout feature is the flexible I/O window ready for MVB (Multifunction Vehicle Bus), designed for project-specific customization. Expansion is further supported by Mini PCIe and M.2 slots for Wi-Fi, LTE, and additional storage.
Operator-Focused HMI with High Visibility
Optimized for driver cabs and onboard control panels, the GOT712A features a sunlight-readable screen with 600 nits of brightness. The integrated auto-dimming light sensor enhances operator comfort while dynamically reducing unnecessary power consumption. It supports projected capacitive (PCAP) touch, with an optional keypad version available for versatile maintenance and operational needs.
“The operational demands on rolling stock require systems that are not just rugged, but also certified to handle both environmental extremes, from wide temperature variations to significant electrical challenges like voltage fluctuations and power surges,” said Violet, Product Manager of TIOT Division at Axiomtek. “The GOT712A is our answer to the railway operators’ most critical needs. Its full railway certification, combined with fanless, power-efficient Intel Atom® computing, directly translates to reduced validation costs, lower maintenance cycles, and guaranteed reliability for long-term HMI deployment."
The Axiomtek GOT712A 12.1-inch XGA TFT LCD fanless railway touch panel PC is now available. For more product information or customization services, please visit our global website at www.axiomtek.com or contact one of our sales representatives at info@axiomtek.com.tw.
Advanced Features of GOT712A
- Sunlight-readable 12.1" XGA TFT LCD
- Intel Atom® processor x6425E, 12W (Elkart Lake)
- M12-type lockable connectors design
- Auto-dimming for different environments
- Operating temperature ranges from -40°C to +70°C (EN 50155 OT4)
- Typical 24 to 110 VDC wide power input range for all types of trains
- EN 50155 and EN 45545-2 certified for railway applications
